32 inch 1920x1080 51PIN LVDS 1500nits LCD Module Back to list

Description:

►Model:DBT320BHN51L150A
►Size : 32 inch
►Resolution:1920x1080 dots
►Active Area:698.4(H)×392.85(V)mm
►Module size:730.4(H)×425.0(V)×18.5(D)mm
►Viewing Angle: 89/89/89/89
►Interface:51PIN LVDS
►Brightness (cd/m²):1500
►Operating Temperature:-30~+80℃
The DBT320BHN51L150A 32 inch LCD module delivers 1920×1080 Full HD resolution, 1500 cd/m² brightness, and –30~+80°C wide temperature endurance. Built for industrial equipment and outdoor advertising machines, it offers durability, clarity, and customization from Duobond Display.

Inquire

The Resilient Performer: 32-Inch Wide Temperature, High Brightness LCD Module

Built for Demanding Applications: Introducing the DBT320BHN51L150A

In the industrial display and outdoor advertising sectors, clarity and durability are paramount. The DBT320BHN51L150A, a 32 inch 1920×1080 LCD module, is engineered to thrive in environments where other panels fail. Its design emphasizes two essential attributes: wide temperature tolerance and high brightness, ensuring consistent performance across extreme climates and under direct sunlight exposure.

From outdoor kiosks to factory control terminals, this LCD module is tailored for projects requiring uninterrupted, crystal-clear visuals in tough operating conditions.

Precision Engineering: Product Specifications

Parameter	Specification	Unit
Model Name	DBT320BHN51L150A	–
Screen Size (Diagonal)	32 (31.51)	inches
Resolution	1920 (H) × 1080 (V), Full HD	pixels
Display Area (Active)	698.4 (H) × 392.85 (V)	mm
Product Dimensions	727.1 (H) × 421.7 (V) × 12.5 (D, Typ.)	mm
Brightness (Center Typ.)	1500	cd/m²
Display Colors	16.7M (8-bit True)	colors
Display Mode	Normally Black, Transmission	–
Weight	5.80 (Typ.)	kg
Power Consumption	LCD Cell: 3.0 (Typ.), Backlight: 78.0 (Typ.)	W
Operating Temperature	–30 ~ +80	°C
Storage Temperature	–30 ~ +80	°C
Surface Treatment	Anti-Glare (Haze 1%), 3H Hardness	–

Key Features

High Brightness: With 1500 cd/m² luminance, this module delivers sharp, vivid images even in direct sunlight.
Wide Temperature Range: Operates reliably from –30°C to +80°C, ensuring stable performance in extreme climates.
Full HD Clarity: 1920×1080 resolution and 16.7M colors provide rich, detailed images for professional applications.
Wide Viewing Angles: ADS technology minimizes color shift, maintaining consistent visibility from multiple perspectives.
Reliable Operation: RoHS-compliant, optimized for 24/7 performance with stable power consumption and long-term durability.

Application Scenarios

Outdoor Advertising Machines: Kiosks, digital signage, and public information displays requiring maximum brightness and durability.
Industrial Equipment: HMIs, automation consoles, and control room terminals where reliability and clarity are essential.
Transportation Systems: Displays for stations, vehicles, and terminals exposed to fluctuating environmental conditions.
Energy & Utilities: Monitoring panels for power plants, oil rigs, and field-deployed systems requiring robust visibility.

About Duobond Display

Duobond Display is a professional LCD module supplier specializing in industrial-grade and commercial display technologies. Our mission is to deliver high-quality, durable, and customizable LCD display solutions across industries such as automation, outdoor digital signage, transportation, and energy.

With years of expertise and global market experience, Duobond Display is a trusted partner for system integrators and OEMs seeking long-term, performance-driven display components. We strictly follow RoHS and ISO standards, ensuring every module is tested for stability, reliability, and compliance.

Our Services

Custom LCD Display Solutions: Engineering tailored for brightness levels, interfaces, dimensions, and coatings.
Wide Temperature & High Brightness Optimization: Enhanced performance in extreme climates with advanced backlight and optical integration.
Technical Consulting: Support for V-by-One/LVDS interface design, power sequencing, and thermal management.
Quality Assurance: Rigorous testing including temperature cycles, humidity resistance, and vibration tolerance.
Global Logistics & After-Sales Support: Reliable supply chain and expert assistance from concept to mass production.

Contact Duobond Display

Looking for a reliable 32 inch LCD module for your next project?
Duobond Display provides both standard high-brightness modules and fully custom LCD displays designed for industrial and outdoor use.
