43 inch 3840x2160 51PIN V-by-One J Shape Curved LCD Display Back to list
Description:

►Model:DBT430DZN51V030A
►Size:43 inch
►Resolution:3840x2160 dots
►Active Area:941.184x529.416mm
►Outline Dimensional:962.66x558x20.5mm
►View Direction:89/89/89/89
►Interface:V-by-One 51PIN
►Brightness:300cd/m²
High-performance 43 inch curved LCD module with 4K resolution, ideal for gaming and slot applications.

Inquire

Ultimate Immersion: 43 Inch Curved LCD Module

In today’s high-end gaming and slot machine markets, the display is the central factor that defines player engagement and drives revenue. Players interact first with the screen, making its visual performance and reliability non-negotiable. To create machines that stand out in a crowded arcade or casino, you need more than a display—you need a window into an immersive gaming experience.

Introducing the DBT430DZN51V030A 43-inch Ultra-High Definition (UHD) Curved LCD Module from Duobond Display. Designed specifically for gaming machines and slot cabinets, this 43 inch curved LCD module combines 3840 × 2160 4K resolution with a precision-engineered curved form factor to deliver an unmatched visual experience. It maximizes player engagement, provides consistent commercial-grade performance, and offers a commanding aesthetic presence on any gaming floor.


Why Choose a Curved LCD Module?

The curved design is not just a stylistic choice—it is a strategic feature that enhances both player experience and visual performance.

1. Maximum Immersion and Engagement

The curved LCD geometry aligns with the natural arc of human vision, creating a wrap-around effect that draws players deeper into the game. For slot machines, this enhances the drama of spinning reels, bonus animations, and jackpots, creating a more engaging and satisfying experience. Increased immersion directly correlates with longer playtime and higher customer retention.

2. Visual Comfort and Uniformity

Flat panels often suffer from edge distortion or reduced brightness when viewed up close. The curved design ensures all pixels are equidistant from the viewer’s eyes, guaranteeing consistent focus, brightness, and color across the screen. This uniformity reduces eye strain, allowing players to enjoy longer sessions comfortably.

3. Premium Aesthetic Presence

In competitive gaming environments, first impressions matter. The curved LCD module adds a sleek, high-tech look that immediately signals superior technology. Machines equipped with curved displays stand out on casino and arcade floors, attracting players and elevating the perceived value of the product.


Uncompromised 4K UHD Visual Performance

The DBT430DZN51V030A offers world-class clarity, color, and brightness to deliver a premium visual experience:

  • 4K UHD Clarity: QFHD resolution (3840 × 2160) provides four times the pixel density of Full HD displays, rendering intricate game assets and UI elements with razor-sharp precision.

  • High Contrast and Brightness: Typical contrast ratio of 5000:1 (Min. 3750:1) and 300 cd/m² luminance ensures deep blacks, bright whites, and high readability even in well-lit environments.

  • Vibrant Colors: Supports 1.07 billion colors (8bit + FRC) and 72% NTSC color saturation, producing rich, lifelike visuals.

  • Ultra-Wide Viewing Angles: 178° horizontal and vertical viewing angles maintain image quality for players or bystanders viewing from off-center positions.

  • Commercial Durability: Anti-Glare surface with Haze 2% and Hard Coating (3H) protects the display from wear and tear in continuous public use.


DBT430DZN51V030A Technical Specifications

Parameter Specification Unit Notes
Model Name DBT430DZN51V030A - 43" UHD Curved LCD Module
Resolution 3840 x 2160 pixel QFHD Resolution
Active Display Area 941.184 x 529.416 mm -
Cell Size 953.3 x 543.15 mm Glass size (Open Cell Outline)
Display Colors 1.07G color 8bit + FRC
Contrast Ratio (Typ/Min) 5000 / 3750 - -
Luminance (Typ.) 300 cd/m² Typical Value
Viewing Angle 178° / 178° degrees H/V (CR ≥ 10)
Surface Treatment Anti-Glare, Haze 2%, Hard Coating (3H) - -
Weight T.B.D kg To Be Determined

About Duobond Display

Duobond Display is a leading LCD module supplier specializing in high-performance, commercial-grade display solutions. We provide custom LCD modules tailored to the needs of gaming machines, slot cabinets, and other professional applications. Our mission is to combine visual excellence, robust engineering, and aesthetic design to deliver displays that perform reliably in demanding 24/7 operational environments.

By leveraging advanced TFT Active Matrix technologies and rigorous manufacturing processes, Duobond Display ensures that every LCD module meets strict commercial durability and performance standards.


Comprehensive LCD Display Solutions

Duobond Display is more than a supplier—we are your LCD display partner. Our services include:

  1. Custom LCD Design & Modification: Tailored displays to your cabinet dimensions, interface requirements, and thermal management needs. This includes panel adjustments, thermal optimization (keeping IC temperature below 120°C), and component placement for perfect integration.

  2. Technical Integration & Software Support: Engineering assistance with power sequencing, signal timing, driver register settings, and Gamma/VCOM calibration for optimal display performance.

  3. Reliability & Durability Guidance: Recommendations to prevent image retention, manage thermal conditions, and maximize long-term product health.

  4. Global Supply Chain Support: High-volume manufacturing capabilities and reliable delivery schedules, ensuring consistent supply for your projects worldwide.


Contact Duobond Display

Ready to transform your gaming machines or slot cabinets with a 43 inch 4K UHD curved LCD module? Contact Duobond Display today to discuss your project:

  • Request a Quote: Detailed pricing for bulk or custom orders.

  • Technical Consultation: Integration support and performance optimization.

  • Custom Display Solutions: Panel modifications, interface adjustments, or specialized mounting options.
